Westminster Abbey 4 music time powerful swinger one piece quartz clock movement

Westminster Abbey 4 music time powerful swinger one piece quartz clock movement for OEM wall clocks, replacement programs, repair kits, and craft clock production. Size: 125*117*33mm. Shaft length: 15mm. Material: ABS plastic+metal.

Model

See product title

Size

125*117*33mm

Product Library

Reference Product Library

Category Path

Products > Cuckoo Clock

• Name: Westminster Temple 4 kinds of music time powerful pendulum all-in-one 12888 quartz clock movement
• Spindle length: total shaft length 15mm, thread length 7mm, suitable for panel thickness of about 2mm-5mm clock use
• Movement size: 125*117*33mm
• Dial fixing mode: screw
• Rocking load: 300g
• Music: There are 4 kinds of music to choose from
• Material: ABS plastic+metal
• Batteries: 2 1.5V C and 1 1.5V AA
• Life span: 8-12 months
• Purpose: Can repair, replace or diy clock
• Accumulation: the screen print on the board is "SET". When this button is triggered, the music selected in the current mode will be played and the number of taps will be accumulated once. (not controlled by the control mode, there is music output when triggered)
• RESET: The screen print on the board is "Reset". When this button is triggered, the initial state is restored
• Presentation: the screen print on the board is "MONITOR". When this button is triggered, only the music selected in the current mode will be played, and the number of taps will not add up. (not controlled by the control mode, there is music output when triggered)
• Control selection mode: the screen printing on the board is "SOUND", and the modes are:
• Program control: 11:00 PM ~ 5:45 AM contact movement trigger no music output
• 24 hours sound: Every hour contact movement trigger has a music output
• Off: There will be no music output for each hour contact movement trigger
• Selection of playing mode: the screen print on the board is "SELECT", and the modes are successively: Mary+clock bell; Westminster+Clock 4*4; Westminster Abbey+Strike the bell; Jingle
• Note: The Westminster+Chime 4*4 mode means that 1/4 bar of Westminster music will be played every 15 minutes/30 minutes/45 minutes of the hour after the contact movement is triggered
• VOLUME adjustment: "Volume" is printed on the board to adjust the volume
